Bullitt - Frame Kit

Larry vs Harry SKU: BFK-YS-EG

Bullitt - Frame Kit

Larry vs Harry SKU: BFK-YS-EG
Regular price $3,249.99 Sale price $2,799.99 Save $450
/
Shipping calculated at checkout.
Questions? Contact us or
.

Within 30 days of your purchase, if you find a lower advertised price for this product, we’ll match it. If we discount this product within 30 days of your purchase, either online or in-store, simply present your original receipt and we’ll match the price and refund you the difference.

To be eligible for a price match, the product must meet the following criteria:

  • Product must have the exact specifications
  • Price must be listed in CAD or USD
  • Final matched price must include all shipping, handling, and duties
  • Must be sold and shipped by an authorized dealer in Canada or the U.S. (excluding Amazon, eBay, or any other online-only retailers)
  • Must be new and not refurbished or liquidated stock
  • Must be in stock and available immediately
  • Price must not be lower due to an error, sale, or discount

To request a price match, visit our store or contact us. Please provide a written quote or a web address for the product showing the lower price.

The legendary Bullitt framekit, the start of your cargo bike project. Here's your chance to build a custom Bullitt that is dialled to your exact specs, or something you can stick all of those old parts you have sitting around in your garage - this is where it begins.

Constructed of 7005 aluminum, the Bullitt frame has its DNA in early bike messengering in Copenhagen, and it's still fundamentally a bike designed for speed, cornering, and efficiency. It's short wheelbase, stiff-as-hell frame, and steep angles make it a cargo rocketship designed to cut time off of deliveries or trips to the daycare. Like any performance bike, it's designed for handling, and that means the cargo is only as safe as your handling skills. Can you handle it? Of course you can!

This is a bike that is ready for any ride and any spec. Want to use a Gates belt drive? Bullitts use a split frame so you're not messing around. Think you might change between derailleur in the summer and internal hub in the winter? Just grab another dropout kit. Want to use big disc rotors in the front wheel for maximum cornering control? You can put on a huge 203mm disc rotor. Easy as that. The hard part is choosing your colour.

  • Questions? Book a consultation with one of our Cargo Bike experts
  • Lightweight 7005 Aluminum frame
  • Cromoly front fork
  • Short wheelbase and low centre of gravity puts less bike and more handling into corners
  • Steep seat and head-tube angles optimize acceleration and handling
  • Super-stiff frame doesn't flex in corners: total mind-bike connection
  • Tapered headset for FSA Orbit XL Pressfit
  • Maximum Capacity: 200kg (Box=100kg, Rider=100kg)
        BULLITT FRAME KIT
        FRAME Super-stiff Aluminum Alloy - Powder-coated
        FORK Cromoly steel w/CNC parts - disc tab: 180-203mm
        STEERING ROD Cromoly - 713mm w/rubber balljoint cover for weather
        WEIGHT CAPACITY 400lbs (rider + payload)
        DROPOUT KITS
        • External gearing w/derailleur hanger & IS discbrake mounting (+ adaptor for front derailleur) & mudguard/fender threads
        • Internal gearing w/IS disc brake mounts & mudguard/fender threads
        • Coaster brake w/coaster brake arm & mudguard/fender threads



        BIKE DIMENSIONS L - 243cm; W - 46.6cm; H - 76cm
        CHASSIS DIMENSIONS L: 724mm bottom, 824mm top, W; 466mm
        SEATPOST DIAMETER 31.6 w/ 34.9 clamp
        BOTTOM BRACKET English thread 68mm
        STEM EXTENSION Satori Easy-up, 100mm up/down
        AXLE WIDTH (F) 100mm
        AXLE WIDTH (R) 135mm
        DISC LIMITATIONS 180mm (R), 180mm-203mm (F)
        FRONT DISC CABLE LENGTH 2350mm
        REAR DISC CABLE LENGTH 1400mm
        FRONT WHEEL SPEC 20" (max tire = 2.0")
        REAR WHEEL SPEC 20" (max tire = 2.0")
        HEADSET FRONT 44/56mm (1.5 / 1"1/8 tapered) inset
        HEADSET REAR 1"1/8th FSA Orbit XL II
        KICKSTAND Reinforced aluminum w/ replaceable plastic feet
        OTHER All bolts, nuts and washers are stainless steel
        WEIGHT 25.4lb
        CRANKS TCP Forged, 42T, 165mm
        COGSET Shimano 22T
        PEDALS Steel axle, resin top
        KICKSTAND None
        RACK Galvanized steel & powder coated - Max 25kg
        FENDERS Galvanized steel &Powder coated
        LOCK Not included
        LIGHTING LED battery powered - 2 front and rear
        STEERING DAMPERS Gas assisted
        ANTI TIP SYSTEM Yes
        KIDS STEP Multiple Step Ups
        SEAT BELTS 4X Three Point Harnesses
        BENCHES Two - Folding
        BIKE DIMENSIONS 217 x 88 x 110 cm
        BOX DIMENSIONS +/- 90 x 58 x 53 cm
        RIDER CAPACITY 100kg
        BOX CAPACITY 100kg
        WEIGHT
        BULLITT FROM TO
        5' 4" 6' 7"
